Configuration Behavior tab

This tab enables you to configure a number of different options related to the deployment of patches.

Select Show summary to see a summary of your custom patch configuration options, with a tab for each operating system. This summary is updated in real time as you add, delete or modify your patch configuration options.

Deployment behavior

This area enables you to configure what patches will be deployed (deployment options), and if and when requests to reboot your target devices will be sent during the deployment process (reboot behavior). You can configure different deployment behaviors for different operating systems in the same patch configuration.

Enabling deployment for an operating system

You can enable and disable patch deployment for each operating system separately. Under Deployment behavior, select the required operating system, then set Deploy patches as required.

To create a scan-only patch configuration, switch off the deployment toggle for all operating system tabs.

Deployment options

The available deployment options depend on the operating system:

Windows: Deploy by severity, Deploy/Exclude by Patch Group, and Selected Vendors/Products
Mac: Deploy by severity, Deploy by Patch Group
Linux: Deploy all missing patches, Deploy by Patch Group

By default, only critical security patches for Windows are deployed. If you:

enable and configure Deploy by severity and set some patch groups to Include in Deploy/Exclude by Patch Group, the effect is additive, with all of the patches for each configured option being deployed
enable and configure Selected Vendors/Products, that option filters out patches from the other two options
set a patch group to Exclude in Deploy/Exclude by Patch Group, then patches that are in a patch group set to Exclude are always excluded even if they are set to be included elsewhere

Example 1: If you want to deploy only those patches that are contained within a patch group:

Disable the Deploy by severity and Selected Vendors/Products options
Enable the Deploy/Exclude by Patch Group option and set the desired patch group to Include

Example 2: Say you configure the following:

Deploy by severity: Security Critical and Security Important are selected
Deploy/Exclude by Patch Group: You set one patch group to Include that contains one Security Critical patch, one Security Important patch, and two Security Moderate patches
Selected Vendors/Products: This option is disabled

In this case:

Security Critical and Security Important patches will be deployed for all vendors and products
all four patches contained in the patch group will be deployed, including the two Security Moderate patches

Example 3: Same as Example 2, but you also:

use the Selected Vendors/Products option to specify that only Adobe patches should be deployed

In this case, the only patches that will be deployed are:

Adobe Security Critical patches, Adobe Security Important patches, and any Adobe patches contained in the patch group

Example 4: Same as Example 3, but you also:

use the Deploy/Exclude by Patch Group option to exclude a patch group that contains a specific Adobe Security Critical patch

In this case, the only patches that will be deployed are:

Adobe Security Critical patches (except for the one in the excluded patch group)
Adobe Security Important patches
any Adobe patches contained in the patch group

If a patch is added to a patch group that is set to Exclude, then the patch will not be deployed, even if other settings specifically suggest it should be deployed.

Example 5 (Windows edge case): Say you configure Deploy by severity with only Security Critical and also configure Deploy by Patch Group to include Vantosi V3.

If Vantosi V4 is then released as Security Critical and, before another patch deployment, Vantosi V5 is released as Security Important then for Windows neither Vantosi V4 nor Vantosi V5 are deployed. This is because the latest version (Vantosi V5) does not meet the Severity requirement for deployment and neither Vantosi V4 nor Vantosi V5 are included in the patch group. Note that if you configured the same patch configuration for Mac, Vantosi V4 would be deployed.

We recommend that you regularly use the Compliance Reporting component to check the compliance status of your devices, and add any new Security Critical patches to a patch group. For more information, see Compliance Reporting and Patch Groups.

Selecting deployment options

Deploy all missing patches / Deploy selected patches (Linux only): For Linux, you can choose to Deploy all missing patches. Alternatively, selecting Deploy selected patches enables further controls so that you can limit which patches are deployed.

Deploy by severity (Windows and Mac): If enabled, allows you to specify the types of patches and the severity levels that should be included in the deployment. By default, only critical security patches is selected.
- Security patches: Security bulletin-related patches. You can choose to deploy one or more specific severity levels.
  - Critical: Vulnerabilities that can be exploited by an unauthenticated remote attacker or vulnerabilities that break guest/host operating system isolation. The exploitation results in the compromise of confidentiality, integrity, availability user data, or processing resources without user interaction. Exploitation could be leveraged to propagate an Internet worm or execute arbitrary code between virtual machines and the host.
  - Important: Vulnerabilities whose exploitation results in the compromise of confidentiality, integrity, or availability of user data and processing resources. Such flaws could allow local users to gain privileges, allow authenticated remote users to execute arbitrary code, or allow local or remote users to easily cause a denial of service.
  - Moderate: Flaws where the ability to exploit is mitigated to a significant degree by configuration or difficulty of exploitation, but in certain deployment scenarios could still lead to some compromise of the confidentiality, integrity, or availability of user data and processing resources. These are the types of vulnerabilities that could have had a critical impact or important impact but are less easily exploited based on a technical evaluation of the flaw, or affect unlikely configurations.
  - Low: All other issues that have a security impact. Vulnerabilities where exploitation is believed to be extremely difficult, or where successful exploitation would have minimal impact.
  - Unassigned: Security patches that have not been assigned a severity level.
- Non-Security patches: Vendor patches that fix known software problems that are not security issues. For Windows, you can choose to deploy for one or more specific vendor severity levels. See Security patches for a description of the available severity levels.
Deploy/Exclude by Patch Group (Windows) or Deploy by Patch Group (Mac and Linux): If enabled, allows you to specify one or more patch groups that contain the patches that you want to include in a deployment or (Windows only) that you want to exclude from deployment. This is a good way to make sure that only approved patches are deployed. Missing patches not contained in patch groups set to Include will not be deployed unless they meet the requirement specified in the Deploy by severity option. Patches in patch groups set to Exclude will not be deployed even if other settings specifically suggest it should be. Details about the available patch groups can be viewed using the Patch Groups tab within the Patch settings page. Patch groups are managed from within Patch Intelligence.
Linux devices are always updated to the latest package available in the repository, even if an earlier version is added to a patch group. Also, not only are packages associated with the advisories in the patch groups installed, but also packages associated with dependent advisories.
When you enable Deploy/Exclude by Patch Group, a grid of all patch groups appears that shows the number of patches for each operating system, plus the total number of patches in each patch group. Select the check box alongside a patch group then click Include or Exclude as appropriate. Click Clear to deselect a patch group.
A or next to the count of patches for the operating system not being configured indicates that the configuration already includes or excludes those patches respectively.
You may want to quickly remind yourself which patches are contained in a group before you select it. To do that, click a numeric link in the grid to display the corresponding patches beneath the Patch Groups grid. Use the Platform column to determine the operating system, and the Status column to determine the status of each individual patch.
The status shown is actually an approximated status based on the use of this patch group with the current patch configuration. A number of factors can affect the patch status. For example, if you use Selected Vendors/Products in conjunction with a patch group, that may filter out one or more patches from the group.
- Active: This patch group has been used by this configuration to make the patch available to the end-user devices. The devices are part of the policies that are associated with this patch configuration.
- Not active: There are two possible reasons for this patch status. (1) This patch group has not been used to make the patch available to any devices. (2) The patch configuration to which this patch group is assigned has not been made active to devices.
  There is a scenario where a patch that is listed as Not active may actually be active. If the patch resides in more than one patch group, one of those other patch groups may have been used to make this patch active to devices.
Selected Vendors/Products (Windows only): If disabled, patches for all available vendors and products will be included in the deployment defined by the Deploy by severity and Deploy by Patch Group options. As new products and patches become available, they will be added to the deployment.

If enabled, it allows you to specify the vendors, product families and product versions that can be deployed to endpoints. Vendors and products that are not selected will be excluded from the deployment. The items are presented in a hierarchical list. If you enable a check box at one level, all check boxes at lower levels are also enabled.

Select All: Enabling this check box selects all currently available patches for all vendors and products in the list. New vendor and product patches that become available at a later date will be added to the deployment.

If you want to exclude a small number of items, you can enable Select All and then clear the check boxes of the items you want to exclude.

Selecting individual vendors and products: Only patches for the selected vendors, product families and/or product versions will be deployed. Unselected vendors and products are filtered out from the deployment.

Reboot Behavior

This area enables you to configure if and when reboots of your target devices are requested during the deployment process. The Ivanti Neurons Platform handles reboot requests centrally to prevent conflicts from different Ivanti Neurons features. This means that the reboot may not be instant when requested.

macOS always reboots after operating system patch deployment, after prompting the user to deploy operating system updates. You can also choose Always reboot after an update (even if no operating system patches applied) for Mac configurations.

Reboot before deployment (Windows only): If enabled, specifies that the target devices are rebooted before patches are deployed. It is considered a best practice to reboot devices before installing significant new software, especially for large software changes such as operating system product levels. If you elect to reboot the devices, you can then specify the amount of warning that a logged-on user will receive and you can choose the degree of control the user will have over the reboot process. You can:
- Elect to force a reboot after a number of minutes have passed
- Alert the user that a reboot will occur when they log off
- Select the duration to display a countdown message when the shutdown sequence is initiated. To preview the dialog box that the user will see, click Example countdown.
- Allow the user to extend the time-out countdown up to a specified maximum.
- Allow the user to cancel the time-out. If a time-out is canceled, the patches will not be deployed until the user logs off or manually reboots the device.
- Allow the user to cancel the reboot. The patches will not be installed until the device is restarted.
Reboot after deployment (Windows and Linux): If enabled, specifies if a reboot of the target devices is requested after patches are deployed. There are two options:
- Always: Specifies that each device is rebooted after the patches are deployed. This is the safest option when deploying patches as most patches require a reboot in order to complete, but there may be times when devices are rebooted unnecessarily.
- When required: Specifies that the Ivanti Neurons agent will determine whether or not a reboot of each device is required based on the patches included in the deployment.

If you elect to reboot the devices, you can then specify further options such as the amount of warning that a logged-on user will receive and the degree of control the user will have over the reboot process using the associated policies. For more information, see Agent Policy Reboot experience.

Scheduling

This area enables you to configure deployments that are performed on a recurring schedule.

The Set recurrence tab enables you to regularly schedule deployment operations at a specific time and using a specified recurrence pattern. For example, a deployment can be run every night at midnight, or every Saturday at 9 PM, every weekday at 11 PM, or at any other user selected time and interval.

Run on reboot if schedule missed: If a scheduled deployment is missed because a device is powered off, it will run within an hour of the device being powered back on.
Deploy patches: You can schedule the patch deployment using the following options:
- Daily: The deployments will run every day of the week at the time of your choosing.
- Weekly: The deployments will run on the specified day of the week at the time of your choosing.
- Monthly: The deployments will run on the specified date or occurrence of a day every month at the time of your choosing. You can also use this option to schedule a deployment in conjunction with Microsoft's Patch Tuesday. For example, you might schedule a monthly patch deployment to occur the day after Patch Tuesday by enabling the Also deploy after Patch Tuesday check box and then specifying 1 as the number of days after Patch Tuesday to delay the deployment.
  The Add delay option adds further flexibility to the scheduling by enabling you add a delay of a number of days to a monthly schedule. For example, if your Change Advisory Board meets on the first Wednesday of each month to agree which patches to deploy on the following Saturday, you could select to deploy on the first Wednesday with a delay of 3 days. This handles the case where the Saturday following the first Wednesday could be either the first or the second Saturday of the month.
- Patch Tuesday: Schedule the deployments to run on the same day as Microsoft's regular monthly patching event, known as Patch Tuesday.

Stage content before deployment: Instructs the patch engine on the endpoint to download patches ahead of the deployment task. This is particularly useful for endpoints with maintenance windows, so that none of the duration of the maintenance window is wasted on the download. You can stage the content anywhere from 1 - 23 hours before the deployment is performed. A patch scan is automatically performed by the agent at the start of the staging process in order to reassess the device's patch status before the deployment.
There is an exception for patch deployments that will occur on the first day of the month. To avoid issues with leap years and other similar quirks in the calendar, the interface prevents you from staging content on the day prior to the first day of the month. For example, if you schedule a deployment for 8:00 am on the first day of the month, you will be allowed to stage content only 1 - 8 hours before the deployment.

Upcoming task: This table shows a list of upcoming tasks. It enables you to view all of the events that are projected to occur over the next 60 days using the currently selected configuration. Note that the information provided in this table is a projection; many things could occur to prevent one or more of the events from occurring.
